NABTESCO精密減速機RDR-C
RDR-C
■產品特點
直交輸入
背隙在1.5分以內
空程在1.5分以內
主軸承內置
附帶對應各公司的伺服電機安裝連接件
已裝入潤滑脂
直接輸入型精密減速機的齒輪箱,中實系列
「附帶對應各公司的伺服電機的安裝連接件」，「已裝入潤滑脂」等，為用戶省去很多麻煩，大大提高了使用便利性。是一款讓用戶更輕松地使用的高性能減速機RV。
■規格
| 序號 | 型號 | 額定轉矩 (kw) | 減速比 | 減速比 | 額定轉矩 （N?m） | 啟動、停止容許轉矩 （N?m） | 額定輸出轉速 （rpm） | 額定壽命 （hr） | 容許輸出轉速 （rpm） | 容許輸入轉速 （rpm） | 齒隙 (arc.min.) | 空程 (arc.min.) | 扭轉剛度 (Nm/arc.min.) | 力矩剛度 (Nm/arc.min.) | 容許力矩① (N?m) |
| 1 | RDR-010C | 0.22 | 81 | 81 | 98 | 245 | 15 | 6,000 | 43 | 3,500 | less than 1.5 | less than 1.5 | 47 | 421 | 686 |
| 2 | RDR-010C | 0.22 | 108 | 108 | 98 | 245 | 15 | 6,000 | 32 | 3,500 | less than 1.5 | less than 1.5 | 47 | 421 | 686 |
| 3 | RDR-010C | 0.22 | 153 | 153 | 98 | 245 | 15 | 6,000 | 23 | 3,500 | less than 1.5 | less than 1.5 | 47 | 421 | 686 |
| 4 | RDR-010C | 0.22 | 189 | 189 | 98 | 245 | 15 | 6,000 | 19 | 3,500 | less than 1.5 | less than 1.5 | 47 | 421 | 686 |
| 5 | RDR-010C | 0.22 | 243 | 243 | 98 | 245 | 15 | 6,000 | 14 | 3,500 | less than 1.5 | less than 1.5 | 47 | 421 | 686 |
| 6 | RDR-027C | 0.594 | 100 | 99.82 | 265 | 662 | 15 | 6,000 | 35 | 3,500 | less than 1.5 | less than 1.5 | 147 | 1,068 | 980 |
| 7 | RDR-027C | 0.594 | 142 | 141.68 | 265 | 662 | 15 | 6,000 | 25 | 3,500 | less than 1.5 | less than 1.5 | 147 | 1,068 | 980 |
| 8 | RDR-027C | 0.594 | 184 | 184 | 265 | 662 | 15 | 6,000 | 19 | 3,500 | less than 1.5 | less than 1.5 | 147 | 1,068 | 980 |
| 9 | RDR-027C | 0.594 | 233 | 233.45 | 265 | 662 | 15 | 6,000 | 15 | 3,500 | less than 1.5 | less than 1.5 | 147 | 1,068 | 980 |
| 10 | RDR-050C | 1.099 | 109 | 109 | 490 | 1,225 | 15 | 6,000 | 28 | 3,000 | less than 1.5 | less than 1.5 | 255 | 1,960 | 1,764 |
| 11 | RDR-050C | 1.099 | 153 | 152.6 | 490 | 1,225 | 15 | 6,000 | 20 | 3,000 | less than 1.5 | less than 1.5 | 255 | 1,960 | 1,764 |
| 12 | RDR-050C | 1.099 | 196 | 196.2 | 490 | 1,225 | 15 | 6,000 | 15 | 3,000 | less than 1.5 | less than 1.5 | 255 | 1,960 | 1,764 |
| 13 | RDR-050C | 1.099 | 240 | 239.8 | 490 | 1,225 | 15 | 6,000 | 13 | 3,000 | less than 1.5 | less than 1.5 | 255 | 1,960 | 1,764 |
| 14 | RDR-100C | 2.198 | 101 | 100.5 | 980 | 2,450 | 15 | 6,000 | 30 | 3,000 | less than 1.5 | less than 1.5 | 510 | 2,813 | 2,450 |
| 15 | RDR-100C | 2.198 | 150 | 150 | 980 | 2,450 | 15 | 6,000 | 20 | 3,000 | less than 1.5 | less than 1.5 | 510 | 2,813 | 2,450 |
| 16 | RDR-100C | 2.198 | 210 | 210 | 980 | 2,450 | 15 | 6,000 | 14 | 3,000 | less than 1.5 | less than 1.5 | 510 | 2,813 | 2,450 |
| 17 | RDR-100C | 2.198 | 258 | 258 | 980 | 2,450 | 15 | 6,000 | 12 | 3,000 | less than 1.5 | less than 1.5 | 510 | 2,813 | 2,450 |
| 18 | RDR-200C | 4.396 | 106 | 105.96 | 1,960 | 4,900 | 15 | 6,000 | 19 | 2,000 | less than 1.5 | less than 1.5 | 980 | 9,800 | 8,820 |
| 19 | RDR-200C | 4.396 | 156 | 155.96 | 1,960 | 4,900 | 15 | 6,000 | 13 | 2,000 | less than 1.5 | less than 1.5 | 980 | 9,800 | 8,820 |
| 20 | RDR-200C | 4.396 | 206 | 206.09 | 1,960 | 4,900 | 15 | 6,000 | 10 | 2,000 | less than 1.5 | less than 1.5 | 980 | 9,800 | 8,820 |
| 21 | RDR-200C | 4.396 | 245 | 245.08 | 1,960 | 4,900 | 15 | 6,000 | 8 | 2,000 | less than 1.5 | less than 1.5 | 980 | 9,800 | 8,820 |
| 22 | RDR-320C | 7.034 | 115 | 115 | 3,136 | 7,840 | 15 | 6,000 | 17 | 2,000 | less than 1.5 | less than 1.5 | 1,960 | 12,740 | 20,580 |
| 23 | RDR-320C | 7.034 | 157 | 157 | 3,136 | 7,840 | 15 | 6,000 | 13 | 2,000 | less than 1.5 | less than 1.5 | 1,960 | 12,740 | 20,580 |
| 24 | RDR-320C | 7.034 | 207 | 207 | 3,136 | 7,840 | 15 | 6,000 | 10 | 2,000 | less than 1.5 | less than 1.5 | 1,960 | 12,740 | 20,580 |
| 25 | RDR-320C | 7.034 | 253 | 253 | 3,136 | 7,840 | 15 | 6,000 | 8 | 2,000 | less than 1.5 | less than 1.5 | 1,960 | 12,740 | 20,580 |
產品展示：
