進口精密齒輪RA-A/NABTESCO帝人減速機RA-A/一件代發

2022-03-10 15:55:59

深圳市日電貿易有限公司

NABTESCO精密減速機RA-A

RA-A

■產品特點

緊湊化

外殼可回轉

背隙在1分以內

空程在1分以內

主軸承內置

附帶對應各公司的伺服電機安裝連接件

已裝入潤滑脂

機床刀庫用齒輪箱（軸回轉型）

是將精密減速機以針對方便機床廠商使用為前提而改良后的齒輪箱。高精度輸出，外殼可旋轉，使其在ATC刀庫、ATC臂、APC 刀塔部位被廣泛采用。在上述用途以外也和RD系列一樣作為精密減速機齒輪箱來應用。

■規格

序號	型號	額定轉矩 (kw)	減速比	減速比	額定轉矩（N?m）	啟動、停止容許轉矩（N?m）	額定輸出轉速	額定壽命	齒隙 (arc.min.)	空程 (arc.min.)	扭轉剛度 (Nm/arc.min.)	力矩剛度 (Nm/arc.min.)	慣性力矩 (kg?m^2)	重量 (kg)	容許力矩① (N?m)
1	RA-20EC	0.375	81	81	167	412	15	6,000	less than 1	less than 1	49	372	0	9.5	882
2	RA-20EC	0.375	105	105	167	412	15	6,000	less than 1	less than 1	49	372	0	9.5	882
3	RA-20EC	0.375	121	121	167	412	15	6,000	less than 1	less than 1	49	372	0	9.5	882
4	RA-20EC	0.375	141	141	167	412	15	6,000	less than 1	less than 1	49	372	0	9.5	882
5	RA-20EC	0.375	161	161	167	412	15	6,000	less than 1	less than 1	49	372	0	9.5	882
6	RA-40EC	0.924	81	81	412	1,029	15	6,000	less than 1	less than 1	108	931	0	20	1,666
7	RA-40EC	0.924	105	105	412	1,029	15	6,000	less than 1	less than 1	108	931	0	20	1,666
8	RA-40EC	0.924	121	121	412	1,029	15	6,000	less than 1	less than 1	108	931	0	20	1,666
9	RA-40EC	0.924	153	153	412	1,029	15	6,000	less than 1	less than 1	108	931	0	20	1,666
10	RA-80EC	1.758	81	81	784	1,960	15	6,000	less than 1	less than 1	196	1,176	0	27	2,156
11	RA-80EC	1.758	101	101	784	1,960	15	6,000	less than 1	less than 1	196	1,176	0	27	2,156
12	RA-80EC	1.758	121	121	784	1,960	15	6,000	less than 1	less than 1	196	1,176	0	27	2,156
13	RA-80EC	1.758	153	153	784	1,960	15	6,000	less than 1	less than 1	196	1,176	0.0000298	27	2,156
14	RA-160EC	3.517	81	81	1,568	3,920	15	6,000	less than 1	less than 1	392	2,940	0.000177	59	3,920
15	RA-160EC	3.517	101	101	1,568	3,920	15	6,000	less than 1	less than 1	392	2,940	0.00014	59	3,920
16	RA-160EC	3.517	129	129	1,568	3,920	15	6,000	less than 1	less than 1	392	2,940	0.000106	59	3,920
17	RA-160EC	3.517	145	145	1,568	3,920	15	6,000	less than 1	less than 1	392	2,940	0.000087	59	3,920
18	RA-160EC	3.517	171	171	1,568	3,920	15	6,000	less than 1	less than 1	392	2,940	0.000074	59	3,920
