帝人齒輪箱RH-N/日本進口NABTESCO納博斯特克RN-N緊湊/輕量
2022-03-11 13:49:38
深圳市日電貿易有限公司
NABTESCO精密減速機RH-N
RH-N
■產品特點
高輸出轉矩
緊湊/輕量
背隙在1分以內
空程在1分以內
主軸承內置
附帶對應各公司的伺服馬達安裝連接件
封入潤滑脂
對應高輸出轉矩的精密減速機齒輪頭型號
擁有「高輸出轉矩」「緊湊」「輕量化」特征的型號。「安裝部品可對應各大廠商的伺服馬達」，「出貨時已經封入潤滑脂」省去客戶的麻煩，提高使用的便利性
■規格
| 序號 | 型號 | 額定轉矩 (kw) | 減速比 | 額定轉矩 （N?m） | 啟動、停止容許轉矩 （N?m） | 額定輸出轉速 （rpm） | 額定壽命 （hr） | 容許輸出轉速 （rpm） | 齒隙 (arc.min.) | 空程 (arc.min.) | 重量 (kg) | 容許力矩① (N?m) | 容許推力① (N) |
| 1 | RH-500N | 10.99 | 81 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 2 | RH-500N | 10.99 | 105 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 3 | RH-500N | 10.99 | 123 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 4 | RH-500N | 10.99 | 144 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 5 | RH-500N | 10.99 | 159 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 6 | RH-500N | 10.99 | 192.75 | 4,900 | 12,250 | 15 | 6,000 | 25 | less than 1 | less than 1 | 61.1 | 11,000 | 32,000 |
| 7 | RH-700N | 15.7 | 105 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
| 8 | RH-700N | 15.7 | 118 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
| 9 | RH-700N | 15.7 | 142.44 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
| 10 | RH-700N | 15.7 | 159 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
| 11 | RH-700N | 15.7 | 183 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
| 12 | RH-700N | 15.7 | 203.52 | 7,000 | 17,500 | 15 | 6,000 | 19 | less than 1 | less than 1 | 106 | 15,000 | 44,000 |
產品展示：
NABTESCO減速機RH-H價格優惠深圳市日電貿易有限公司有售OVO
如您需要請聯系電話：13316589227 / 0755-83725565 QQ：348575394
歡迎您的來電
