RDS-C齒輪箱/NABTESCO帝人減速機/進口納博特斯克/原裝進口
2022-03-11 08:59:59
深圳市日電貿易有限公司
NABTESCO精密減速機RDS-E
RDS-E
■產品特點
已裝入潤滑脂
背隙在1分以內
空程在1分以內
主軸承內置
附帶對應各公司的伺服電機安裝連接件
直接輸入型精密減速機的齒輪箱，中實系列
「附帶對應各公司的伺服電機的安裝連接件」，「已裝入潤滑脂」等，為用戶省去很多麻煩，大大提高了使用便利性。是一款讓用戶更輕松地使用的高性能減速機RV。
■規格
| 序號 | 型號 | 額定轉矩 (kw) | 減速比 | 減速比 | 額定轉矩 （N?m） | 啟動、停止容許轉矩 （N?m） | 額定輸出轉速 （rpm） | 額定壽命 （hr） | 容許輸入轉速 （rpm） | 齒隙 (arc.min.) | 空程 (arc.min.) | 扭轉剛度 (Nm/arc.min.) | 力矩剛度 (Nm/arc.min. | 容許力矩① (N?m) |
| 1 | RDS-006E | 0.26 | 31 | 31 | 58 | 117 | 30 | 6,000 | 3,500 | less than 1.5 | less than 1.5 | 20 | 117 | 196 |
| 2 | RDS-006E | 0.26 | 43 | 43 | 58 | 117 | 30 | 6,000 | 3,500 | less than 1.5 | less than 1.5 | 20 | 117 | 196 |
| 3 | RDS-006E | 0.26 | 54 | 54 | 58 | 117 | 30 | 6,000 | 3,500 | less than 1.5 | less than 1.5 | 20 | 117 | 196 |
| 4 | RDS-006E | 0.26 | 79 | 79 | 58 | 117 | 30 | 6,000 | 3,500 | less than 1.5 | less than 1.5 | 20 | 117 | 196 |
| 5 | RDS-006E | 0.26 | 103 | 103 | 58 | 117 | 30 | 6,000 | 3,500 | less than 1.5 | less than 1.5 | 20 | 117 | 196 |
| 6 | RDS-020E | 0.38 | 41 | 41 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 7 | RDS-020E | 0.38 | 57 | 57 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 8 | RDS-020E | 0.38 | 81 | 81 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 9 | RDS-020E | 0.38 | 105 | 105 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 10 | RDS-020E | 0.38 | 121 | 121 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 11 | RDS-020E | 0.38 | 161 | 161 | 167 | 412 | 15 | 6,000 | 3,500 | less than 1 | less than 1 | 49 | 372 | 882 |
| 12 | RDS-040E | 0.92 | 41 | 41 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 13 | RDS-040E | 0.92 | 57 | 57 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 14 | RDS-040E | 0.92 | 81 | 81 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 15 | RDS-040E | 0.92 | 105 | 105 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 16 | RDS-040E | 0.92 | 121 | 121 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 17 | RDS-040E | 0.92 | 153 | 153 | 412 | 1,029 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 108 | 931 | 1,666 |
| 18 | RDS-080E | 1.76 | 41 | 41 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 19 | RDS-080E | 1.76 | 57 | 57 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 20 | RDS-080E | 1.76 | 81 | 81 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 21 | RDS-080E | 1.76 | 101 | 101 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 22 | RDS-080E | 1.76 | 121 | 121 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 23 | RDS-080E | 1.76 | 153 | 153 | 784 | 1,960 | 15 | 6,000 | 3,000 | less than 1 | less than 1 | 196 | 1,176 | 2,156 |
| 24 | RDS-160E | 3.52 | 66 | 66 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 25 | RDS-160E | 3.52 | 81 | 81 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 26 | RDS-160E | 3.52 | 101 | 101 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 27 | RDS-160E | 3.52 | 121 | 121 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 28 | RDS-160E | 3.52 | 145 | 145 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 29 | RDS-160E | 3.52 | 171 | 171 | 1,568 | 3,920 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 392 | 2,940 | 3,920 |
| 30 | RDS-320E | 7.03 | 66 | 66 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
| 31 | RDS-320E | 7.03 | 81 | 81 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
| 32 | RDS-320E | 7.03 | 101 | 101 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
| 33 | RDS-320E | 7.03 | 121 | 121 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
| 34 | RDS-320E | 7.03 | 141 | 141 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
| 35 | RDS-320E | 7.03 | 185 | 185 | 3,136 | 7,840 | 15 | 6,000 | 2,000 | less than 1 | less than 1 | 980 | 4,900 | 7,056 |
產品展示：
NABTESCO減速機RDS-E價格優惠深圳市日電貿易有限公司有售OVO
如您需要請聯系電話：13316589227 / 0755-83725565 QQ：348575394
歡迎您的來電
