齒輪箱NABTESCO/精密減速機GH-P/法蘭輸出型/減速機AF-C/一件代發
2022-03-10 15:56:34
深圳市日電貿易有限公司
NABTESCO精密減速機GH-P
GH-P
■產品特點
高速旋轉
主軸承內置
附帶對應各公司的伺服電機安裝連接件
已裝入潤滑脂
可高速旋轉的精密減速機的齒輪箱,法蘭輸出型。
由于「附帶對應各公司的伺服電機的安裝連接件」，「已封入潤滑脂」，使得用戶的使用范圍大幅度上升，行走軸、升降軸等在各種地方被廣泛使用。
■規格
| 序號 | 型號 | 額定轉矩 (kw) | 減速比 | 減速比 | 額定轉矩 （N?m） | 啟動、停止容許轉矩 （N?m） | 額定輸出轉速 （rpm） | 額定壽命 （hr） | 齒隙 (arc.min.) | 空程 (arc.min.) | 慣性力矩 (kg?m^2) | 重量 (kg) | 容許力矩① (N?m) |
| 1 | GH7 | 0.52 | 11 | 11.24390244 | 69 | 206 | 50 | 6,000 | less than 6 | less than 6 | 0 | 8 | 460 |
| 2 | GH7 | 0.52 | 21 | 21 | 69 | 206 | 50 | 6,000 | less than 6 | less than 6 | 0 | 8 | 460 |
| 3 | GH7 | 0.52 | 31 | 30.6 | 69 | 206 | 50 | 6,000 | less than 6 | less than 6 | 0 | 8 | 460 |
| 4 | GH17 | 1.25 | 11 | 11 | 167 | 500 | 50 | 6,000 | less than 6 | less than 6 | 0 | 15.5 | 804 |
| 5 | GH17 | 1.25 | 21 | 21 | 167 | 500 | 50 | 6,000 | less than 6 | less than 6 | 0 | 15.5 | 804 |
| 6 | GH17 | 1.25 | 31 | 31 | 167 | 500 | 50 | 6,000 | less than 6 | less than 6 | 0 | 15.5 | 804 |
| 7 | GH24 | 1.76 | 11 | 11 | 235 | 706 | 50 | 6,000 | less than 6 | less than 6 | 0.000148 | 15.5 | 843 |
| 8 | GH24 | 1.76 | 21 | 21 | 235 | 706 | 50 | 6,000 | less than 6 | less than 6 | 0.0000656 | 15.5 | 843 |
| 9 | GH24 | 1.76 | 31 | 31 | 235 | 706 | 50 | 6,000 | less than 6 | less than 6 | 0.0000472 | 15.5 | 843 |
| 10 | GH40 | 2.94 | 11 | 10.74358974 | 393 | 1,176 | 50 | 6,000 | less than 6 | less than 6 | 0.000826 | 35.5 | 1,823 |
| 11 | GH40 | 2.93 | 21 | 21 | 392 | 1,176 | 50 | 6,000 | less than 6 | less than 6 | 0.00041 | 35.5 | 1,823 |
| 12 | GH40 | 2.93 | 31 | 31.43478261 | 392 | 1,176 | 50 | 6,000 | less than 6 | less than 6 | 0.000306 | 35.5 | 1,823 |
| 13 | GH100 | 7.33 | 21 | 20.375 | 980 | 2,942 | 50 | 6,000 | less than 10 | less than 10 | 0.00149 | 90 | 4,900 |
| 14 | GH100 | 7.33 | 31 | 31.4 | 980 | 2,942 | 50 | 6,000 | less than 10 | less than 10 | 0.00114 | 90 | 4,900 |
■細節展示
NABTESCO減速機GH-P價格優惠深圳市日電貿易有限公司有售OVO
如您需要請聯系電話：13316589227 / 0755-83725565 QQ：348575394
歡迎您的來電
